| Prefabricated Steel Structure Building Description: QINGDAO KXD STEEL STRUCTURE CO.,LTD |
KXD Steel Structure Products
Crafted with precision and utilizing premium-grade steel, our steel
structure products exemplify unmatched strength, enduring
durability, and extraordinary flexibility. Tailored for
versatility, they seamlessly adapt to many applications such as
industrial edifices, commercial complexes, and residential
developments. Engineered for simplicity in installation and upkeep,
these structures offer economical solutions without compromising
structural soundness and safety.
| Item | Materials |
| Main steel frame | column and beam | Q235, Q355 steel, paint, or galvanization |
| wind resistant column | Q235, Q355 steel, paint, or galvanization |
| Secondary bracing | Roof purlin | Q235B C/Z section galvanized steel |
| Wall purlin | Q235B C/Z section galvanized steel |
| Tie bar | Q235,φ89*3 round steel pipe |
| knee brace | angle steel ,Q235,L50*4 |
| roof horizontal bracing | φ20, Q235B steel bar, paint or galvanized |
| column vertical bracing | φ20 , Q235B steel bar, paint or galvanized |
| casing pipe | φ32*2.0,Q235 steel pipe |
| Pulling bar | Φ10 round bar Q235 |
| Roof and wall | Wall and roof panel | corrugated steel sheet/sandwich panel |
| protecting system | gutter | color steel sheet/galvanized steel/stainless steel |
| Trim and flashing | color steel sheet |
| downspout | PVC |
| self-tapping screw | |
| Fastener system | Anchor bolts | Q235 steel |
| High strength bolt | The Specifications shall be determined according to the design of
the steel structure. |
| Normal bolt |
| Nuts |
| Window and door | Window | Aluminum windows |
| Door | Depending on the requirement, the door can be an EPS door, a
windproof door, a high-speed roll-up door, or an industrial sliding
door. |
Product Features
- High Strength: Engineered to support colossal weights, guaranteeing unwavering
structural stability.
- Durability: Built to endure, our structures boast an impressive lifespan,
withstanding wear and tear over time.
- Lightweight: Facilitates effortless transportation and swift installation.
- Quick Assembly: Prefabricated components are meticulously crafted for rapid
construction and seamless assembly.
- Large span: Effortlessly bridges expansive spaces, minimizing the necessity
for multiple interim support structures.
- Versatility: Perfectly adaptable, catering to a rich variety of architectural
blueprints.
- Cost-Effective: Contributes to substantial savings in both long-term maintenance
and upfront construction costs.
- Eco-Friendly: Constructed from recyclable steel, our products champion
environmental sustainability and reduced ecological impact.
These Prefabricated Steel buildings are easy to assemble, energy
efficient, attractive, economical over time, and can be shipped in
as little as 5 weeks. Our Engineers and staff are always on standby
to assist with complex projects.
Our steel structure building has a flexible layout, has low
foundation cost, and can designed as per the buyer's requirement
1. Location (where will be built?) Which country? which city?
2. Size: Length * width * Eve height _______ mm * _______ mm *
_______ mm
3. wind load (maximum. Wind speed) _____ kn/m2, _____ km/h, _____
m/s
4. snow load (maximum Snow height) _____ kn/m2, _____ mm,
temperature range?
5. Anti-earthquake _____ level
6. brick wall needed or not If yes, is 1.2m high or 1.5m high? or
other?
7. thermal insulation If yes, EPS, fiberglass wool, rock wool, and
PU sandwich panels will be suggested; If not, the metal steel
sheets will be ok. The cost of the latter will be much lower than
that of the former.
8. Door quantity&size _____ units, _____ (width) mm * _____
(height) mm
9. window quantity&size _____ units, _____ (width) mm * _____
(height) mm
10. crane needed or not If yes, _____ units, max. Lifting
weight____tons; Max. Lifting height _____m
Product Parameters
Main steel structure frame :
Material: Weld H beam or hot rolled H beam etc
Grade:Q355 (S355JR)
Surface: Hot dip Galvanized zinc coated or Anti-rust paint
rich-zinc epoxy paint etc
Usage: Make up the main steel structure frame |
Strut (Tie beam) on eave and ridge:
Material: Round pipe or square tube etc
Grade:Q235 (S235JR)
Surface: Hot dip Galvanized zinc coat or Anti-rust paint rich-zinc
epoxy paint etc
Usage: Avoid the main steel structure frame shake in the length
direction
X brace for roof and wall:
Material: Steel Round bar or angle steel etc
Grade:Q235 (S235JR)
Surface: Hot dip Galvanized zinc coat or Anti-rust paint rich-zinc
epoxy paint etc
Usage: Make the whole structure stable, tie the whole building into
one
● Windows and Doors
Plastic Steel Window/Aluminum-alloy Window; Sliding Door/Folding
Door.
● Other Options:
The gutter, Downpipe, Transparent sheet, Ventilator, and Bridge
Crane will be fitted according to the client’s
requirements.
Our company can design, fabricate, load, and erect steel structure
buildings according to clients’ needs.
1. Make suitable design plans and detailed construction drawings of
steel structure buildings according to the land layout area and
usage of buildings by Tekla, PKPM, and 3D3S.
2. Steel structure buildings consultation service.
3. Budget offers of building for contractors.
4. Transportation & delivery as your need.
5. Fabrication, shot blasting & painting as different requests.
6. Erection & installation of steel structure building. Our
technicians and skilled workers can be on-site to guide or install
the building as needed
Why Choose KXD Steel Structure Building?
1. One-stop service:
Total solution for projects; 3D model design; design drawing and
construction drawing; online technical support; after service:
return and replacement.
2. Well-equipped factory:
Our own factory-patented packaging and convenient transportation
save you from worries.
3. High-quality products:
Our own professional research & development team and the QC team
guarantee that our customers will receive products with perfect
welding and accurate dimensions.
4. Rich experience:
Our products have been exported to America, Russia, Saudi Arabia,
Canada, Romania, Sri Lanka, Malawi, British, the Philippines, Greece, South Africa, and so on.
5. Constantly develop:
We have been devoted to the research & development of steel
structure buildings. And we constantly renovate technology to
improve the wind- and rain-resistance performance of the products.
So their lifespan can be enlarged and it helps accomplish the most
cost-effective effect for our customers.
FAQ
Q: Are you a manufacturer or trading company?
A: We are a manufacturing factory, located in Qingdao City, near
Qingdao Port. We have a total of 3 workshops from steel structures
to wall and roof sheets.
Q: How about your quality control?
A: We have certificates ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, and loading to ensure no quality defects.
Q: Is third-party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirements.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to the order
quantity, partial shipment is allowed for big orders.
Q: What about the installation?
A: We'll provide the detailed installation drawing, and supervisors
guiding installation are available. We can do turnkey jobs for some
kinds of projects.
Q: How to ensure the product you supply is what we want exactly?
A: The sales and engineering team will provide you with a suitable
solution according to your requirements before placing an order.
Proposal drawings, Shop drawings, 3D drawings, Materials photos,
and Finished projects photos are available, which will help you
understand the solution we provided deeply.
