Product Description:
The Steel Structure Workshop comes with a variety of roofing and
wall options, including EPS, Glass Wool, Rock Wool, and PU. These
materials provide excellent insulation, ensuring that the structure
remains comfortable and energy-efficient. The roofing and wall
options are customizable, allowing you to choose the best fit for
your specific needs.
The surface of the Steel Structure Workshop can be painted or
galvanized, depending on your preference. Galvanized Steel
Structure is an excellent choice if you require an added layer of
protection against rust and corrosion. A painted surface is perfect
if you want to add a pop of color or match the aesthetics of your
existing structures.
Installation of the Steel Structure Workshop is easy, with engineer
guidance provided on-site. Our engineers will ensure that the
structure is assembled correctly and safely, taking into account
any unique requirements that you may have.
In summary, our Steel Structure Workshop is an excellent choice for
those in need of a durable, reliable, and energy-efficient
structure. Built to GB Standard, it is made with heavy Galvanized
Steel Structure Frames and comes with a variety of roofing and wall
options. The surface can be painted or galvanized, and installation
is easy with engineer guidance provided on-site. Choose our Steel
Structure Workshop for your next industrial or commercial project
and enjoy the benefits of a high-quality structure that meets your
unique needs.
Technical Parameters:
| Application: | steel structure, China steel structure , steel structure China
,steel warehouse, steel structure building, steel structure
warehouse, steel workshop, steel structure workshop,hangar, sport
hall, steel hall,shopping mall, cow shed, poultry house ,etc |
| Clear span:(width) | 6~50m without middle column |
| Height | 2~20m |
| Length | as your requirement |
| Material Grade | Q345(S355JR)or Q235(S235JR) steel or as request |
| Column & Rafter | Welded or Hot rolled H beam |
| Tie beam | round pipe or square tube or as request |
| X brace | round steel bar, angle steel or as request |
| Purlin | C purlin, Z purlin,thickness 2.0mm,2.2mm,2.5mm,3.0mm |
| sag rod | steel round bar, angle, C purlin etc |
| Wall & Roof coverage | single corrugated steel sheet (0.12~1.2mm) |
| EPS, Rock wool, glass fiber ,PU core foam sandwich Panel |
| (Thickness:50mm,75mm,100mm,150mm,200mm) |
| Gate | Electric roller shutter door/Sliding door |
| Exit Door | Plastic steel/Aluminum alloy swing door/ steel swing door |
| Window | Plastic steel or Aluminum alloy frame |
| sliding window/ vent/top Hung window |
| Surface | Shot blasting with anti rust paint rich-zinc epoxy paint etc |
| hot dip galvanize |
| Certificate | ISO90001,CE EN1090 |
| Quality Control | The third party ,SGS, QIMA, BV all accept |
| Crane | 5MT, 10MT, 15MT, etc. |
| Other accessories | gutter, flashing trimming cover, down spout, ventilation fitting, |
| skylight belt, bolt, anchor bolt, self tapping screw etc |
| Package | main steel frame etc load in 40'OT,roof and wall panel load in
40'HQ! |
Applications:
The Steel Structure Workshop is designed to withstand heavy snow
loads of 0.5-1.0KN/m². The door type can be customized according to
the client's requirements, with options ranging from sliding,
rolling, or sectional doors. The surface of the construction can be
painted or galvanized.
The main material used in the Steel Structure Workshop is steel
structure frames, ensuring a sturdy and long-lasting construction.
The main frame is made of light steel Q345 Q235, which is a strong
and durable material. The Steel Structure Workshop is suitable for
various construction projects and building construction scenarios.
Support and Services:
Our Steel Structure Workshop product comes with comprehensive
technical support and services to ensure a smooth and successful
installation process. Our team of experts is available to provide
guidance and assistance at every stage of the project, from design
to construction. We offer detailed product specifications, CAD
drawings, and engineering calculations to help you make informed
decisions and ensure compliance with industry standards. In
addition, we provide on-site installation supervision and training
to ensure that the installation is carried out to the highest
standards of safety and quality. Our goal is to ensure that you
have a reliable and durable workshop that meets your specific needs
and requirements.
Packing and Shipping:
Product Packaging:
- Steel structure components will be packaged in bundles and secured
with steel straps.
- All the wall and roof panels will be packaged in bundles and
secured with steel straps.
- All the windows and doors will be packaged with cartons.
- All the necessary fittings and accessories will be packaged with
cartons or bags.
- The loading procedure will be supervised by our experienced staff
to ensure the safety of the goods during transportation.
Shipping:
- We can arrange shipping by sea or by train to any destination
worldwide.
- We will provide all necessary shipping documents, including packing
lists, commercial invoices, and bills of lading.
- We will keep in touch with you throughout the shipping process to
ensure that you receive the goods on time and in good condition.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
