Product Description:
| Application: | steel structure, China steel structure , steel structure China
,steel warehouse, steel structure building, steel structure
warehouse, steel workshop, steel structure workshop,hangar, sport
hall, steel hall,shopping mall, cow shed, poultry house ,etc |
| Clear span:(width) | 6~50m without middle column |
| Height | 2~20m |
| Length | as your requirement |
| Material Grade | Q345(S355JR)or Q235(S235JR) steel or as request |
| Column & Rafter | Welded or Hot rolled H beam |
| Tie beam | round pipe or square tube or as request |
| X brace | round steel bar, angle steel or as request |
| Purlin | C purlin, Z purlin,thickness 2.0mm,2.2mm,2.5mm,3.0mm |
| sag rod | steel round bar, angle, C purlin etc |
| Wall & Roof coverage | single corrugated steel sheet (0.12~1.2mm) |
| EPS, Rock wool, glass fiber ,PU core foam sandwich Panel |
| (Thickness:50mm,75mm,100mm,150mm,200mm) |
| Gate | Electric roller shutter door/Sliding door |
| Exit Door | Plastic steel/Aluminum alloy swing door/ steel swing door |
| Window | Plastic steel or Aluminum alloy frame |
| sliding window/ vent/top Hung window |
| Surface | Shot blasting with anti rust paint rich-zinc epoxy paint etc |
| hot dip galvanize |
| Certificate | ISO90001,CE EN1090 EXC2 ,IWE etc |
| Quality Control | The third party ,SGS, QIMA, BV all accept |
| Crane | 5MT, 10MT, 15MT, etc. |
| Other accessories | gutter, flashing trimming cover, down spout, ventilation fitting, |
| skylight belt, bolt, anchor bolt, self tapping screw etc |
| Package | main steel frame etc load in 40'OT,roof and wall panel load in
40'HQ! |
Steel structure building is one kind of product which can be design
as per every proples' different need. So,if you found that follows example pictures is not as same as
your want, even it is very different.
Do not worried,
No matter which kind of building you need, prefabricated houses
warehouse bigger, smaller or multi-storey, just tell me the data or
drawing of building what you need.
We will make the exact design, quotation and rendering for you as
soon as we can.
Technical Parameters:
| Name | Steel Structure Workshop/Warehouse |
| Dimensions | Length | H beam: 4000-15000mm |
| Thickness: | web plate: 6-32mm |
| wing plate: 6-40mm |
| Height | 200-2400mm |
| Color | According to customers |
| Size | MOQ is 200 m2, width * length * eave height, |
| Advantages | 1. Lower cost but beautiful outlook. |
| 2. High safety performance. |
| 3. easy to assemble and dismantle |
| 4. manufacture under complete quality control system---ISO9001 |
| 5. installation with instruction of experienced engineers |
| 6. Non-pollution. |
| Main components | Base | Cement and steel foundation bolts |
| Main frame | H beam |
| Material | Q235B, Q345B or others as buyers' requests. |
| Purlin | C or Z purlin: Size from C120~C320, Z100~Z200 |
| Bracing | X-type or other type bracing made from angle, round pipe |
| Bolt | Plain bolt and High-strenth bolt |
| Roof & wall | Sandwich panel or color plate |
| Door | Sliding or rolling door |
| Window | Aluminium alloy window |
| Surface | Two lays of Anti-rust Painting or Hot Dip Galvanized |
| Sheet | 0.5mm or 0.6mm galvanized sheet |
| Accessories | Semi-transparent skylight belts, Ventilators, |
| down pipe, Glavanized gutter, etc |
| Usages | 1. workshop, warehouse, plant |
| 2. Steel web frame structure |
| 3. Steel H-column and steel H-beam |
| 4. Portal frame products |
| 5. High rise building project |
| 6. Others steel structure buildings |
| Packing | Main steel frame without packing load in 40' OT, |
| roof and wall panel load in 40' HQ! |
| Drawing: | According to drawings or according to customer ' s requirement. |
| Design Parameters | If you need we design for you, please supply us the following
parameter |
| together with detail size: |
| 1) length, width, height, eave height, roof pitch, etc |
| 2) wind load, snow load, raining condition, aseismatic
requirements, etc |
| 4) Demands for doors and windows |
| 5)Other information if necessary |
| | |
Applications:
The roof and wall thickness for the product is around 50mm, 75mm,
100mm, 120mm, 150mm, and 200mm. The beams used in the product are H
Beams, and the raw steel material used is Q235B and Q355B. The
purlin used in the product is galvanized C or Z type steel. The
roof and wall cladding used in the product includes EPS, Glass
Wool, Rock Wool, and PU.
KXD Steel Structure WH2766 is perfect for a wide range of product
application occasions and scenarios. The product is perfect for use
in automated warehouse solutions, cold room warehouses, and
logistic centers. The steel structure warehouse is also perfect for
use in manufacturing plants, storage facilities, and distribution
centers. The product is ideal for use in industries such as
automotive, food and beverage, agriculture, and retail.
Support and Services:
Our Steel Structure Warehouse product comes with comprehensive
technical support and services to ensure that you get the most out
of your purchase.
Our team of experts is available to provide assistance with
installation, maintenance, and troubleshooting to help you overcome
any challenges you may encounter.
In addition, we offer ongoing training and education to help you
optimize the performance and longevity of your steel structure.
Whether you have questions about design, materials, or
construction, we are here to help you every step of the way.
Our commitment to customer satisfaction means that we will work
with you to identify and resolve any issues that may arise,
providing prompt and effective solutions that minimize downtime and
maximize productivity.
Trust us to be your partner in achieving success with our Steel
Structure Warehouse product.
Packing and Shipping:
Product Packaging:
- All components will be packed in steel pallets or wooden cases.
- Roof and wall panels will be wrapped with plastic film to prevent
scratches.
- All bolts and screws will be put in small bags and labeled for easy
identification.
- The package will be reinforced with straps for safe transportation.
Shipping:
- The steel structure warehouse will be shipped in containers by sea
or by train.
- The delivery time will vary depending on the destination and
shipping method.
- The customer will be notified of the estimated delivery time and
provided with a tracking number.
- Upon arrival, the customer should inspect the package for any
damages before signing the delivery receipt.
- If any damages are found, the customer should take pictures and
contact the seller immediately for assistance.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
