Workshop Automated Warehouse Racking Systems with Skylight and
Customizable Design
Product Description:
Our steel structure warehouse comes with a variety of roof and wall
cladding options, including EPS, glass wool, rock wool, and PU.
These options allow you to choose the best insulation for your
warehouse, depending on your needs. In addition, our warehouse
comes with skylights made from glass fiber reinforced plastics.
This allows natural light to enter the building, reducing the need
for artificial lighting and saving you money on energy costs.
Our steel structure warehouse is available in a range of
dimensions, allowing you to choose the size that best suits your
needs. Whether you need a small warehouse for a start-up business
or a large warehouse for an established company, we can provide you
with the perfect solution.
*Length | Customized according to customer requirements, allowing flexibility
to meet specific project needs. |
*Width | Available in single span, double-span, and multi-span
configurations to suit various structural designs. |
*Height | Adjustable to customer requirements, ensuring the structure fits
perfectly into the intended space. |
Features:
- Product Name: Steel Structure Warehouse
- Connect: Bolt/Weld
- Roofing: Sandwich Panel, Single Steel Sheet
- Roof & wall cladding: EPS, Glass Wool, Rock Wool, PU
- Dimension: Customers' Requirement
- Roof & wall thickness: Around 50mm, 75mm, 100mm, 120mm, 150mm,
200mm
- Features: Automated Warehouse Racking Systems, Custom Steel
Fabrication
Column and Beam | Column: Made from Q235 or Q345 welded H section steel, providing robust
support and stability.Beam: Constructed from Q235 or Q345 welded section steel, offering
strength and durability for the structure. |
Purlin | Crafted from Q235 C channel or Z channel, ensuring reliable secondary structural support for the roof. |
Vertical and Transversal Support | Made from Q235 angle steel, round bar, or steel pipe, these
supports offer additional stability and strength |
Cladding System | Options include EPS, PU, Fiber Glass, and Rock Wool sandwich panels or corrugated steel sheets with fiberglass wool
insulation.Available in various colors and gauges to meet aesthetic and
functional requirements. |
Applications:
| Specifications |
| 1)Size(m): | Width * Length * Height; |
| 2)Type: | Single slope, double slope, Multi-slope; |
| Single span, double-span, Multi-span; |
| Single floor, double-floor, Multi-floor; |
| 3) Base: | steel foundation bolts |
| 4) Steel frame: | Material Q345(S355JR)(Gr50)or Q235(S235JR) steel; |
| Straight cross-section or Variable cross-section; |
| steel welded H section painted or galvanized. |
| 5) Bracing: | X-type or V-type or other type bracing made from angle, round bar,
etc ; |
| 6) Wall & Roof Purlin: | C section channel or Z section channel ,Size from C80~C300;
Z100~Z300; |
| 7) Roof & wall cladding | Single color corrugated steel sheet 0.326~0.7mm thickness; |
| Sandwich panel with EPS, ROCK WOOL,GLASS WOOL, PU etc insulation,
thickness around 50mm 75mm 100mm 120mm 150mm 200mm; |
| recommend coating PVDF SMP HDP PE |
| 8)Window: | UPVC/PVC or Aluminum Alloy window frame with glass. |
| 9)Door: | Exterior door:Sliding or Roller shutter door. |
| Internal door:50mm thickness EPS sandwich panel with an aluminum
alloy door frame |
| 10) Gutter material: | Color steel sheet or galvanized steel or stainless steel; |
| 11)Rainspout: | PVC pipe |
| 12)Connection | high strength bolts ,intensive bolt,self-drilling screws. |
| 13)Accessories: | Skylight panel, Ventilation, Fasteners etc |
| 14)Surface process: | Shot blasting Sa2.5;Two layers of Anti-rust Painting or galvanized |
| 15) Packing: | Main steel frame without packing load in 40' GP, roof and wall
panel load in 40' HQ |
.
Support and Services:
This product comes with technical support and services to ensure
proper installation and maintenance of the steel structure
warehouse. Our team of experts can assist with:
1. We can offer you the manual include the photos and drawings, or
some videos for help you on the installation. And you will organize
the local people to install it.
2. We can send our people to your site to guide your people to
install. Or send team people (3-5 people) to your site to install
for you. This way is most easy way, but you need to pay their
round-way tickets, local food, accommodation, transportation,
communication and salary, and also their security on the site.
3. You can send your people (engineers or the technician) to our
co- mpany to study the installation details.
Our goal is to ensure that our customers have a safe and reliable
steel structure warehouse that meets their specific needs and
requirements.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
