Industrial Factory Building Construction Prefabricated Modular
Steel Structure Plant Prefab Steel Frame Warehouse
Product Description:
Our steel structure warehouse is fully customizable to meet your
specific needs and requirements. You can choose between roller
shutter doors or sliding doors to fit your needs and ensure easy
access for your employees and equipment.
The dimensions of the steel structure warehouse can be tailored to
the unique needs and space constraints of your business. We
understand that every business has different storage needs, so we
will work with you to design and construct a warehouse that meets
your requirements.
1. We supply one-stop service from 3D model, design drawing and construction drawing, online
technical support, to return and replacement.
2. With patented pallet, it is easily to load and unload.
3. Nice appearance, smooth surface and different painting color
options for customized.
4. Stable and durable, could assist strong wind and heavy snow.
5. Cost-effective, low cost and fast construction, the materials can be recycled.
Features:
- Product Name: Steel Structure Warehouse
- Features:
- Steel Frame Warehouse
- Beam: H Beam
- Roof & wall cladding : EPS, Glass Wool, Rock Wool, PU
- Roofing: Sandwich Panel, Single Steel Sheet
- Drawing Plan: As Buyer's Requirements
- Automated Warehouse Solutions
- Intelligent Warehouse Management System
- Custom Steel Fabrication
| Item | Material | Description and surface process |
| Main steel frame | Column and Beam | Q235 or Q355 | H section steel with two coats of mid-gray paint |
| Purlin | Q235 or Q355 | Galvanized C or Z type steel |
| Connecting Pieces | Tie tube | Q235 | Circular Tube with two coats of mid-gray paint |
| Knee-Bracing | Q235 | L50*4 Galvanized angle steel |
| Strutting piece | Q235 | φ12*2.5 Galvanized Circular Tube |
| Column Bracing | Q235 | Circular Tube with two coats of mid-gray paint |
| Horizontal Bracing | Q235 | Circular Tube with two coats of mid-gray paint |
| Casing | Q235 | φ30*2.5 Galvanized Circular Tube |
| Door and Window | Item | Description |
| Door | Roller shutter door or Sliding door |
| Window | PVC Window or aluminum alloy window |
| Other parts | Ventilating device | Fan,Ventilation window |
| Bolt | Foundation bolt,High strengthen bolt, Normal bolts |
| Skylight | Yx-840 Glass Fiber Reinforced Plastics |
| Out/Inner ridge tile | 0.50mm Color sheet |
| Crane beam | Q235 or Q345 H section steel with two coats of mid-gray paint |
| Panel Material parts | (1). External Wall panel: (below is selectable) |
| 1) 50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| 4) 50- 250mm thickness PU sandwich panel |
| 3) 900# Corrugated Galvanized Steel sheet with different Color |
| 4) Kinds of PVC wall panel. |
| (2). Internal Wall panel: (below is selectable) |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| (3). Roofing panel: (below is selectable) |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| 3)Corrugated Steel Sheet, an insulating layer if need. |
| 4)Corrugated PVC roof panel. |
| (4). Skylight: 820# Glass Fiber Reinforced Plastics (FRP) |
Applications:
The steel structure warehouse from KXD is suitable for a variety of
product application occasions and scenarios. It is ideal for
automated warehouse solutions, as it can be customized to fit the
specific requirements of the warehouse. The steel frame warehouse
is also perfect for industrial warehouse shelving, as it is strong
and durable enough to hold heavy-duty equipment and goods.
The product is designed with automated warehouse racking systems in
mind, making it easy to integrate with existing systems. The steel
structure warehouse is also built to withstand harsh weather
conditions, making it perfect for use in areas prone to natural
disasters such as earthquakes and hurricanes.
The warehouse is built with skylight made of glass fiber reinforced
plastics, allowing natural light to enter the building. The roofing
options available for the product include sandwich panel and single
steel sheet. The steel frame warehouse is connected through
bolt/weld and purlin is made of galvanized C or Z type steel.
Support and Services:
Our Steel Structure Warehouse product comes with comprehensive
technical support and services to ensure the best user experience.
Our team of experts is available to answer any questions or
concerns you may have regarding the product design, installation,
or maintenance. We also offer on-site support services and training
for your staff to ensure proper usage and maintenance of the steel
structure warehouse. Our technical support and services aim to
provide you with the necessary resources and knowledge to maximize
the performance and longevity of your steel structure warehouse.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
